EMS iris+ - Page 14

Iris 12V OUT
INPUT 8
INPUT 7
INPUT 6
INPUT 5
INPUT 4
INPUT 3
INPUT 2
INPUT 1
OPTO 0V
Iris 0V OUT
12Vdc output which can be used if required, to trigger inputs 1-8.
Hardwired Input 8 programmable for N/O or N/C operation.
5-12Vdc applied or removed to trigger dependant on
programming.
Hardwired Input 7 programmable for N/O or N/C operation.
5-12Vdc applied or removed to trigger dependant on
programming.
Hardwired Input 6 programmable for N/O or N/C operation.
5-12Vdc applied or removed to trigger dependant on
programming.
Hardwired Input 5 programmable for N/O or N/C operation.
5-12Vdc applied or removed to trigger dependant on
programming.
Hardwired Input 4 programmable for N/O or N/C operation.
5-12Vdc applied or removed to trigger dependant on
programming.
Hardwired Input 3 programmable for N/O or N/C operation.
5-12Vdc applied or removed to trigger dependant on
programming.
Hardwired Input 2 programmable for N/O or N/C operation.
5-12Vdc applied or removed to trigger dependant on
programming.
Hardwired Input 1 programmable for N/O or N/C operation.
5-12Vdc applied or removed to trigger dependant on
programming.
Requires 0Vdc to be applied to enable a positive voltage to
trigger inputs 1-8.
0Vdc output which is normally linked to the OPTO 0V connection
to enable a positive voltage to trigger inputs 1-8.
Page 14 of 32
