Transmitter grouping
Each of the transmitters programmed into Iris can be allocated to a transmitter group. These groups
can then be assigned to make one or more relays operate. This will allow a wide variety of options to
be set up where designated transmitters will operate specic relays.
The Menu structure for the Grouping Task is shown below.
*T-Groups*
View Grouping
Change Grouping
*Main Menu*
PINs & Access
System Support
Serial Comms
Pager Setup
Engineer Ctrl
Time & Date
Radio Setup
Output Setup
Logging
Relay Setup
Remote Rxers
Direct Inputs
Network
Txer Grouping
Bus I/O
Change Grouping: Selecting this option allows the various groups to be altered. There are a
maximum of 16 groups available. Each group can have its event congured. The event can be best
described as the way the group will respond to a signal. The valid options are shown below:
Event options
Alarm
Local
P-Call
X-Alarm
X-Local
Any
None
Group response
An Alarm signal from any transmitter in the group.
A Local signal from any transmitter in the group.
A P-Call alarm signal from any personnel call transmitter in the group.
Any Local or P-Call signal but NOT an Alarm signal from any transmitter
in the group.
Any Alarm or P-Call signal but NOT a Local signal from any transmitter in
the group.
Any signal from any transmitter in the group.
No operation
