The following example shows how to congure Output 4 (Relay 3) to change state upon an alarm
transmission. This example could be used to operate a Piezo Sounder. Follow the steps listed below:
Access the Main Menu by following the operations listed under the previous ‘Accessing the
engineering menus ’ section.
Press the  button until the screen displays:
Press the  button. The screen will change to display:
Press the  button until the screen displays:
Press the  button. The screen will change to display:
Press the  button. The screen will change to display:
Press the  button until the screen displays the required
output to congure: In this example, Output 4.
Note: An alternative event type can be selected from pg25.
Press the  button. The screen will change to display:
Press the  button once and the screen will display:
Press the  button until the screen displays the required
action:
In this example, Group: ‘Alarm’
Press the  button. The screen will change to display:
Press the 3 key until SYSTEM RESET is displayed and turn
the keyswitch to the Clear position to exit the menu.
| Radio Setup |
> Output Setup <
| Logging |
2=Help 14:05
| ** Binary Outputs ** |
> Test Outputs <
| Output Latch Times |
2=Help 14:05
1
| Output Permissions |
> Output On Reasons <
| Output O Reasons |
2=Help 14:05
Output On Reasons
1 = Change On Reason
3 = Exit / Finish
2=Help 14:05
1
Edit on Reason
for Output 3
1 = deselect reason
2=Help 14:05
| * Select on Reason * |
> NOTHING <
|---------------------------------|
2=Help 14:05
1
|---------------------------------|
> Group: ‘Alarm’ <
|---------------------------------|
2=Help 14:06
1
| * Output on Reason * |
> 1 / ‘Un-named’ is <
| Switched on by |
2=Help 14:05
|-------------------------------- |
> 3 / ‘Un-named’ is <
| Switched on by |
2=Help 14:05
1
1
|---------------------------------|
>*REASON*SELECTED* <
| Group: ‘Alarm’ |
2=Help 14:06
