EMS PIEZON BUILT-IN BIK User Manual

5
Wiring diagram
13
12
B
A
11
10
4
3
2
1
9
8
7
6
5
4
3
2
1
The strain relief wire must be
attached tightly to the connector
or to the unit frame when no
connector is used
Note: The indicated wire colors for the module control bundle are valid for the universal standard bundle only.
IMPORTANT NOTICE:
For AC installation connect (12)DCI to (2)DCO
For DC installation remove (2)DCO
All unused wires must be isolated separately
Note: installation of a
connector is recommended.
(not supplied in kit)
Module EJ-110
Water
Cold water supply
1.0 - 2.0 bars
(100 - 200 kPa)
Adjustable flow rate
0-50ml/min ±10
MODULE
TYPE E
MODULE
TYPE F
MODULE
TYPE G
MODULE
TYPE H
Control voltage
0 - 5 Vdc
Scaler ON/OFF:
with power supply
Do not connect
yellow (ONL) wire in
that case
Scaler ON/OFF:
with power supply
Do not connect
yellow (ONL) wire in
that case
Scaler switch:
ON: 0VL
OFF: 5V / Open
Control voltage
0 - 5 Vdc
Control voltage
0 - 10 Vdc
Control voltage
0 - 10 Vdc
Scaler switch:
ON: 0VL
OFF: 5V / Open
DC installation:
32V DC (±10%)
Supply voltage:
AC installation:
24V AC (±10%)
OR
clear tubing
gray
white
violet
pink
white
brown
yellow
orange
black
violet
red
+
0V
Power regulation:
Potentiometer: 2.2 kΩ
Power regulation:
Potentiometer: 2.2 kΩ
+
+
0V
+
0V
+
0V
blue
blue
green
