Emtek CF 2.0 - CF Cassette Installation; Step 5 A: Install Spindle and Cassette A; Step 5 B: Install Cassette B; Rosette Installation

3
English
5. Install CF Cassees
Step 5B: 

Step 5A: 

For Privacy Funcon ensure the
hole in the Cassee aligns with the
privacy pin hole in the Latch.
Spring
Step 6A: 
For privacy funcon, ensure the privacy pin hole
in the rosee is on the side closest to the door
edge and aligns with the hole in the Cassee
6. Install the Rosees
Step 6B: 

For levers only: Remove the rotaon card
aer installaon of Cassee.
!
!
!
!
