EM TEST (Switzerland) GmbH CWS500 N1.3 / N1.4
User manual V 1.01 45 / 47
Delivery Groups
Basic equipment
- Continuous wave simulator type CWS 500N1.3 or CWS 500N1.4
- Mains cable
- Calibration certificate
- icd.control software on delivered USB memory stick
- 1 x BNC cable 0.5m,
- 1 x N cable 0.5 m + 1 x N cable 1.5 m
- 20 dB / 1W attenuator
- N-connector bridge (AMP OUT – COUPLER IN)
Safety manual
Identical accessory parts are delivered only once if several devices are orderes. The delivered packing list is in
each case valid for the delivery.
Options
Coupling networks (CDN) as per IEC 61000-4-6 Wide range of different CDN’s
Coupling clamps EM clamp as per IEC 61000-4-6 for coupling of the RF signal to multiple cables.
Current injection clamp acc. To IEC 61000-4-6
Current Probe acc. IEC 61000-4-6
6 dB attenuator ATT 6/80 6dB/80W
50- matching resistor T-50 50 as matching resistor for CDN’s
150 to 50 adapter R-100N 100 as per IEC 61000-4-6, Ref plane: 100 mm x 100 mm
R-100N1 100 as per IEC 61000-4-6, Ref plane: 150 mm x 150 mm
R-100A 100 with N-type-connector for current clamp calibration
Calibration adapters For all types of CDN’s and clamps (manufactured and delivered
by EM TEST)
User software " icd.control "
- Test, analysis and documentation with windows
- License version for testing according the most industrial standards
- Report generator with export function to word-processing software
