EM TEST UCS 500 Series
Operating Manual V 5.40 8 / 99
Special models
Special models have the index UCS500Nx Sx. The difference to the standard models are: Voltage- and current
ranges. The operation is the same as by the standard UCS equipment’s.
Model Pulse voltage
CDN
UCS 500 M4 S1 4kV
250V 32A single phase
UCS 500 M4 S2 4kV
690V 16A single phase
UCS 500 M4 S3 4kV
690V 32A single phase
UCS 500 M4 S5 4kV
280V 16A single phase
UCS 500 M6 S2 6kV
690V 16A single phase
ANSI
Model
Pulse EUT
Modules
UCS 500 M6B S1
6kV 250V 32A
EFT/6, VCS/6 and PFS/6; 1ph CDN 250V / 32A (ANSI)
module RWG/6 not available
UCS 500 M6B S2
6kV 690V 16A
EFT/6, VCS/6 and PFS/6; 1ph CDN 690V / 16A (ANSI) 480V dc
module RWG/6 not available
1.2.
Standards covered by UCS N Series
A fully equipped UCS 500N covers the following standards
UCS 500
N5
N7
- IEC 61000-4-4
Burst
X
X
- IEC 61000-4-5
Surge
X
X
- IEC 61000-4-8
50/60Hz Magnetic Field
X
X
- IEC 61000-4-9
Pulse Magnetic Field
X
X
- IEC 61000-4-11
Voltage Dips
Voltage Interruptions
Voltage Variations for ac power mains supply
X
X
- IEC 61000-4-12
Ringwave
X
- IEC 61000-4-29
Voltage Interruptions
Voltage Dips for dc power supply systems
X
X
- ANSI
Surge with 2 coupling
X
- ITU and ETS
Telecom Surge
(X)
(X)
- FCC
Part 68
(X)
(X)
