EM TEST UCS 500 Series
Operating Manual V 5.40 85 / 99
13.7.2.
Pulse 10 / 700s as per IEC 61000-4-5
Voltage verification
Test level : 4000 V (for N5 type max. 5000V; respectively 7000V for N7 Type).
Pulse : 10 / 700s open circuit voltage waveshape
Output : on 25 output (internal 40 (15 + 25))
Load : open circuit
Tolerances no load
U peak
Tf
Td
pulse 10 / 700s
2000 V +/- 10%
10s +/- 30%
700s +/- 20%
Current verification
Test level : 4000 V (for N5 type max. 5000V; respectively 7000V for N7 Type).
Pulse : 5 / 320s short circuit current wave shape
Output : on 25 output (internal 40 (15 + 25))
Load : short circuit
Tolerances
I peak
Tf
Td
short circuit
100 A +/- 10%
5 s +/- 20%
320 s +/- 20%
13.7.3.
Pulse 9 / 720s as per FCC
Voltage verification
Test level : 2000 V (for N5 type max. 5000V; respectively 7000V for N7 Type)
Pulse : 9 / 720s open circuit voltage wave shape
Output : on 25 output (internal 40 (15 + 25))
Load : open circuit
Tolerances no load
U peak
Tf
Td
pulse 9 / 720s
2000 V +/- 10%
9 s +/- 30%
720s +/- 20%
Current verification
Test level : 2000 V (for N5 type max. 5000V; respectively 7000V for N7 Type).
Pulse : 5 / 330s short circuit current wave shape
Output : on 25 output (internal 40 (15 + 25))
Load : short circuit
Tolerances
I peak
Tf
Td
short circuit
50 A +/- 10%
5 s +/- 20%
330 s +/- 20%
