EMX CR-2000 - Specifications and Connections; Technical Specifications; Wiring Designations and Functions

CR-2000 Instructions Rev 1.5 3
Date 6/28/2018
Specifications
Specifications
Power Supply
9-25VDC
Power Supply Tolerance
+/- 20% of Power Rating
Current Draw Standby
</= 30mA
Read Range
1.1 in (3cm) – 3.1in (8cm)
Capacity (users)
2000 Car and or Pass Codes
Temperature Range
-13ºF (-25ºC) to 140ºF (60ºC)
Operating Humidity
10% ~ 90%
Electric Lock Output
</= 3A
Alarm Output
</= 20A
Short Circuit Protection Time
</= 100uS
Activation Time
0-99 Seconds (Adjustable)
Size
4.74in (120mm) x 2.2in(56mm) x 0.71in(18mm)
Certifications
CE
Connections
No.
Designation
Color
Function
1
Bell-A
Pink
Door Bell Terminal A
2
Bell-B
Pale Blue
Door Bell Terminal B
3
D0
Green
WG Output Line (D0)
4
D1
White
WG Output Line (D1)
5
Alarm
Grey
Alarm Negative (Alarm positive connected to +12V
6
Open
Yellow
Exit Button (Other end of exit button connected to GND)
7
D-IN
Brown
Magnet Switch(Other end of magnet SW connected to GND)
8
AC/DC+
RED
Power 9-25V DC + Input
9
AC/DC-
Black
Power 9-25V DC - Input
10
N/O
Blue
Relay Internal Contact (Normally Open)
11
COM
Purple
Relay Internal Contact (Common)
12
N/C
Orange
Relay Internal Contact (Normally Closed)
13
GND
Shield
Ground (Earth Ground)
