Egress (Exit) Delay & Warning
8 5 0 #
8 5 1 #
8 5 2 #
8 5 3 #
8 5 4 #
After pressing the egress button, output 1 activates with no delay or
warning.
After pressing the egress button, the keypad will beep for 5 seconds
before output 1 activates.
After pressing the egress button, the keypad will beep for 10 seconds
before output 1 activates.
Press and hold the egress button for 5 seconds, the keypad will beep
before output 1 activates.
Press and hold the egress button for 10 seconds, the keypad will
beep before output 1 activates.
Troubleshooting
Symptom Possible Cause Solution
Forgotten
programming key
Forgotten
programming key
1. Disconnect the power supply.
2. Move the DAP jumper from OFF to ON.
3. Reconnect the power supply. The keypad will
start beeping.
4. Move the DAP jumper back to the OFF position.
The keypad will stop beeping.
5. The keypad is now in programming mode
and the programming key is now 0000.
(This does not affect stored data, only the programming
key is forgotten.)
Steel
box
Plastic inner box
Faceplate
Mounting the Keypad
