Enco 25 - Specifications and Features; Technical Specifications

- -
5
1.SPECIFICATION
MODEL 31(BS) / 31N2F(BS) 25
Drilling capacity 32mm(1
1
/
4
") 25 mm (1")
Face mill capacity 76mm(3") 64 mm (2-1/2")
End mill capacity 20mm(3/4") 13mm (1/2")
Spindle nose to column surface 170mm(6-3/4") 170mm(6-3/4")
Max. distance spindle nose to table 430mm(16-7/8") 325 mm(12-3/4")
Spindle tape
r
M.T.3 R-8 M.T.3 R-8
Spindle stroke 130mm(5-1/8")(N2F=107mm) 90 mm (3-1/2")
Diameter of Spindle sleeve 75mm(3") 62 mm (2-7/16")
Head swivel
360∘ 360∘
Diameter of column 115mm(4-1/2") 92 mm (3-5/8")
Overall height (w/o stand) 1240mm(48-7/8") 1050 mm (41-3/8")
Length 990mm(39") 910mm(35-7/8")
Width 1100mm(43-3/8") 960mm(37-7/8")
M
achine stand height 715mm(28-1/8") 715mm(28-1/8")
Moto
r
1-1/2HP - 2HP 3/4HP – 1HP
50Hz 125-2500 90-2150 Spindle spee
d
( r.p.m.)
12S
60Hz 150-3000 110-2580
Standard accessories 3"-cutter 1/2" chuck 3 " angle
vise
2
1
/
2
" –cutter 1/2" chuck
3" angle vise
Forward and backward travel of
table
185mm(7-1/4") 150 mm (5-7/8")
Right and left travel of table 430mm(16-7/8") 340 mm (13-3/8")
Working area of table 730mm x 210mm(28
3
/
4
"x 8
1
/
4
") 585mm x 190mm(23"x 7
1
/
2
")
Gross weight 300kgs (660 lbs) 200kgs (440 lbs)
Measurement 20’Container Q’ty: 42 sets 20’Container Q’ty: 48 sets
Extra accessories
Power down (spindle) feed
Tapping switch
Forward & Reverse switch
Collet chuck
Work light
Cabinet stand
Extension
column Clamping kits
Forward & Reverse switch
Collet chuck
Work light
Cabinet stand
Clamping kits
Noise 80 dB MAX 80 dB MAX
