WPS Current Status: If the wireless security (encryption) function of this
wireless router is properly set, you’ll see a ‘Configured’
message here. Otherwise, you’ll see ‘UnConfigured’.
Click the “Release Configuration” can clear the security
settings of the 1
st
SSID.
Self Pin Code: This is the WPS PIN code of the wireless router. You may need
this information when connecting to other WPS-enabled
wireless devices.
SSID: This is the network broadcast name (SSID) of the router.
Authentication Mode: It shows the active authentication mode for the wireless
connection.
Passphrase Key: It shows the passphrase key that is randomly generated by
the wireless router during the WPS process. You may need
this information when using a device which doesn’t support
WPS.
Interface: If device is set to repeater mode, you can choose “Client” interface to
connect with other AP by using WPS, otherwise you may choose
“AP” interface to do WPS with other clients.
WPS via Push Button: Press the button to start the WPS process. The router
will wait for the WPS request from the wireless devices
within 2 minutes.
WPS via PIN: You can fill-in the PIN code of the wireless device and press the
button to start the WPS process. The router will wait for the WPS
request from the wireless device within 2 minutes.
54
