ENXTV-3 - User Manual
5
1.2 System Requirements
z LCD, CRT or other types of monitors/projectors with PC VGA (D-sub) input.
z A computer is necessary when in PIP mode. No specific PC system required.
z Video source (broadcast TV, cable TV, PC, DVD Player, camcorder, game console,
etc.)
1.3 Specifications
TV format NTSC, PAL, SECAM
Resolution
Output video mode: 4:3
(800x600, 1024x768, 1280x1024, 1400x1050)
Output video mode: 16:10
(1440x900, 1680x1050, 1920x1200)
Output video mode: 16:9
(1920x1080)
TV input 75 Ohm impedance, F or PH type
Video input RCA Video in, S-Video in and YPbPr in
Audio input
RCA L/R,
3.5mm connector (for PC use)
Audio output 3.5mm connector
RGB output D-SUB 15 Pin
Environmental:
Operating Temperature:0°C~40 °C
Storage Temperature: -5°C~50°C
Operating Humidity: 0%~80% RH, non-condensing
Certification
CE, FCC, RoHS
