Specifications
Range 20 µ
m to 125 mm
Drive / sieving motion electromagnetic 3D
Max. Batch / feed capacity 6 kg
Max. Number of fractions 6 full height / 12 half height (300 mm or 12”)
Amplitude 0 - 2 mm digital setting in 10 steps
Speed 3,000 min
-1
at 50 Hz
Time display digital, 0:10-99:50 min
Interval operation yes (one mode)
Suitable for dry sieving yes
Suitable for wet sieving yes
Serial interface -
Sieve diameter 100 / 150 / 200 / 250 / 300 / 315 mm or 3” / 8” / 12”
Clamping device quick-release clamping system (included)
Model bench top or floor standing
Protection code IP 54
Electrical supply different voltages available
Power connection 1 – Phase
Ø x H 427mm x 240 mm (without clamping unit)
Net weight ~ 45 kg
Standards CE
Noise characteristic values:
Example 1:
Emission value related to workplace LpAeq = 63 dB (A)
(Operating conditions: Material to be sieved = quartz sand, grain size < 1mm, 5 sieves Amplitude =
1.5 mm)
Example 2:
Emission value related to workplace LpAeq = 67 dB (A)
(Operating conditions: Material to be sieved = quartz sand, grain size < 1mm, 5 sieves Amplitude =
3 mm)
