Endecotts Minor 200 - Controls and Functions

62
Copyright © 2015 by Endecotts Ltd.
1. Setting up
Controls and functions
The sieve shaker should be placed on a level surface to ensure symmetrical distribution of the sample
over the sieve mesh. The surface should be rigid and robust where vibration will not cause problems.
Operators should be familiar with and fully understand the controls and indicators before
operating this machine. This should be done in conjunction with the diagram below and control
panel description.
CLAMP PLATE
CLAMP HAND
WHEELS
SIEVE STACK
LARGE PLAIN
CLAMP WASHERS
ROUND
CLAMP RODS
REMOVABLE
CONTROL BOX
FUSE HOLDER
MAINS POWER
CONNECTION
MAINS SWITCH
INTERFACE FOR
CONTROL BOX
