Place one hand on the top of the clamp plate (figure 3) and hold square while locking one side handle
lever. Repeat for the opposite side handle lever.
The side handle levers can be set vertically downwards by pressing on the Red button and pulling
the handle outwards to release (figure 4). Turn the handle to a safe, convenient angle downwards and
release to engage the teeth. Screw the two clamping hand wheels down simultaneously to ensure the
clamping plate is square.
Continue until the hand wheels are tight against the internal stop. Hand tightness must be exerted so
that the assembly does not loosen during vibration.
The locking side handle levers and clamping hand wheels must be tightened sufficiently to ensure
that the sieves and receiver are clamped securely during operation.
5. Set time and amplitude.
6. Press START
