The transit bolts are fixed to the underneath of the device.
Use a 13 mm wrench to attach and remove the four screws.
Place the Titan 450 on a stable floor, since otherwise unpleasant vibrations will be
transmitted. Being placed on a level surface ensures symmetrical distribution of the sample
over the sieves, during operation.
• Unscrew the two hexagon screws (transit bolts) on the bottom of the sieve shaker with
an open ended spanner until the sieve plate is movable.
• Keep hexagon screws (transit bolts) for possible transport at a later date.
IMPORTANT
If the machine is operated with the transit bolts
, or is transported without
transit bolts, mechanical components may become damaged.
Reusing transit bolts
• Dismount the clamping unit.
• Screw the hexagon screws (transit bolts) into the two holes on the bottom of the sieve
shaker and tighten with open ended spanner until the sieve plate is no longer
movable.
