Page 4
108
7
5
4
96
2
31
7.5’
50”
20.5”
14”
14”
15’
MAIN DRAIN
EQUIPMENT COMPARTMENT DOOR
1.75” ELECTRICAL
CUTOUT
1.75” ELECTRICAL
CUTOUT
108
7
5
4
96
2
31
7.5’
50”
20.5”
14”
14”
15’
MAIN DRAIN
EQUIPMENT COMPARTMENT DOOR
1.75” ELECTRICAL
CUTOUT
1.75” ELECTRICAL
CUTOUT
R200
R220
R500
X500
12’
GROUND PREPARATION
A reinforced concrete pad at least six inches thick or a deck that is able to withstand more than 250 lbs. per square foot is required
for the
Aquatic Fitness System
As a homeowner, it is your responsibility to provide a suitable, level foundation for your
system. Keep in mind that most delivery crews are not equipped to level and prepare system sites.
If you are interested in having a concrete slab, your ENDLESS POOLS dealer should be able to suggest a qualified, licensed
contractor.
NOTE: In order for the system to operate properly and the internal plumbing to drain completely, you must ensure that the system
is level.
