Hardware Pack Check List
11
-5-
Assembly Pack Check List
Step2
Step3
Step1
#117 - 3/8" x16.5 x2.0T x4H
Split Washer (6 pcs)
#144 - 3/8”-16 x 3”
Button Head Socket Bolt (6 pcs)
#134 - M5 x 12mm
Phillips Head Screw (4 pcs)
#116 -ψ3/8" x 35 x 2T
Flat Washer (6 pcs)
#134 - M5 x 12mm
Phillips Head Screw (4 pcs)
#117 - 3/8" x16.5 x2.0T x4H
Split Washer (6 pcs)
#125 -ψ3/8" x25 x2T
Flat Washer (6 pcs)
#145 – 3/8”-16 x3/4”
Button Head Socket Bolt (6 pcs)
#146 – M8 x1.25x12mm
Socket Head Cap Bolt (6 pcs)
