Enel X JuiceRouter - Page 9

9
1
Gland base
2
Split washer
3
Rubber seal
4
Spacer
5
Cap
3. Route the Ethernet cable through the cap, spacer, rubber seal, and split washer.
NOTE
These components have a “clamshell” design that allows them to be installed onto
the cable.
4. Compress the split washer, rubber seal, and spacer so that they t together inside the
cap.
