We are grateful that we have been able to convince you of the benets of
CTM Therapy® and that you have bought the CTM Controller® 1600.
The CTM Controller® 1600 is a very light, mobile cold and heat therapy
device for using CTM Therapy®, which supports improved rehabilitation
and pain management. The CTM Controller® 1600 enables controlled
cold treatment in a constant therapeutic temperature range of 8 to 18°C
(46 to 64°F) and controlled heat treatment in a constant therapeutic
temperature range of 38 to 42°C (100 to 108°F).
Please read this operating manual through thoroughly, so as to guarantee
the maximum safety and benets of the CTM Controller® 1600.
The CTM Controller® 1600 is intended to be used by physicians and
patients.
Patients can operate the device after an adequate training by qualied
clinicians, no restrictions in functions described in this User Manual
are applied.
The CTM Controller® 1600 is designed to be used for a period of 10 years
when subjected to regular maintenance.
The CTM Exchanger® shall be used for one patient only for the extension
of the treatment.
Table of contents
A. Important safety information 4
B. General safety and usage instructions 5
C. Components 6
Control unit 7
Control panel 7
D. CTM Controller® 1600 setup 8
Connecting the tube and the CTM Exchanger® 9
Filling the control unit with water 9
E. Operation 10
Recommended procedure for therapeutic cooling 10
Recommended procedure for therapeutic heating 11
Display current temperature 11
Timer function 11
F. Maintenance 12
G. Troubleshooting 12
H. CTM Exchanger® 14
Appendix A – Explanation of symbols 15
Appendix B – Manufacturer‘s declaration 16
Ener-C | CTM Controller® 1600 | Operating manual | Rev. 1.1 | 2017-12-12 Ener-C | CTM Controller® 1600 | Operating manual | Rev. 1.1 | 2017-12-12
CTM Controller® 1600 specications and data
Weight (net) 5.0 kg (control unit)
Dimensions 300 mm x 260 mm x 184 mm
Input 230 V, 50 Hz, 260 W
Water temperature 8 °C – 42 °C (normal tap water)
Operating temperature 5 °C – 35 °C (optimal room temperature below 25 °C) *
Transport and storage temperature 5 °C – 40 °C *
* Relative humidity 10% to 90%
