C. Components
The components of the CTM Controller® 1600
1 Control unit
1 Set of tubes
1 CTM Exchanger®
There are a large number of CTM Exchanger® available for use with the CTM Controller® 1600
(see section H. CTM Exchanger®).
NOTE: The tube may be dierent in appearance from the above example.
The control unit
Cover of the
water tank
Air inlet
Handle
Mains cable
The control panel / display symbols
Low water
level
Power Timer HeatingCooling
FLASHING
Enter Temperature scale
Timer
On/O
Warmer
Cooler
Enter
Temperature scale choice
Tube CTM Exchanger® Control unit
Water level indicator (on side)
Ener-C | CTM Controller® 1600 | Operating manual | C. Components | Rev. 1.1 | 2017-12-12 Ener-C | CTM Controller® 1600 | Operating manual | C. Components | Rev. 1.1 | 2017-12-12
Control panel
Warning: User interface keys are very sensitive to touch, inadvertently touching could modify
the parameters.
