Battery bank 2 voltage (V)
Shows the voltage of battery bank 2 (connected to
the +B2 input). This value will only be shown when the
+B2 input is con gured as a second battery input (see
Function F2.0).
Battery bank 3 voltage (V)
Shows the voltage of battery bank 3 (connected to the
+B3 input). This value will only be shown when the +B3
input is con gured as a third battery input (see Function
F3.0).
Main battery current (A)
Shows the current owing in- or out of the main battery.
A negative sign indicates a discharge current and a
positive sign a charge current.
Main battery power (W)
Shows the power draw from the main battery (negative
sign) or the power ow into the battery (positive sign).
This reading is turned o
by default and can be turned
on in Function F9.2.
