Energetics XT 1010 User Manual

9
Part
Description
Qty
Part
Description
Qty
1
Main Frame
1
38
Power Adaptor
1
2
Pedal Arm (L)
1
39
Ø82_Slide Wheel , Urethane
2
3
Pedal Arm (R)
1
40~1
3/8" × 2"_Flat Head Socket Bolt
3
4
Lower Handle Bar (L)
1
40~2
Ø35 × 10m/m_Rubber Foot
3
5
Lower Handle Bar (R)
1
41
Console Mast Cover(L)
1
6
Bushing Housing, Pedal Arm
2
41~1
Console Mast Cover(R)
1
7
Connecting Arm (L)
1
42
Side Case (L)
1
8
Connecting Arm (R)
1
43
Side Case (R)
1
9
Cross Bar
2
44
Round Disk
2
10
Console Mast
1
45
Round Disk Cover
2
11
Idler Wheel Assembly
1
47
Pedal Arm Cover (L)
1
12
Crank Axle
1
48
Pedal Arm Cover (R)
1
13
Swing Arm (L)
1
50
Pedal (L)
1
14
Swing Arm (R)
1
51
Pedal (R)
1
15
Rail Assembly
1
52
Slide Wheel Cover
2
16
Rail Tube
2
53
Ø32(1.8T)_Button Head Plug
4
17
Axle for Pedal
2
54
Front Handle Bar Cover (L)
1
18
Axle for Slide Wheel
2
55
Rear Handle Bar Cover (L)
1
19
Ø11.9 × Ø8.5 × 15m/m_Rod End
Sleeve
3
56
Front Handle Bar Cover (R)
1
20
6005_Bearing
2
57
Rear Handle Bar Cover (R)
1
21
6203_Bearing
2
58
32 × 2.5T_Round Cap
2
22
6003_Bearing
8
59
Connecting Arm Cover A (L)
2
23
M12 × P1.75_Rod End Bearing
2
60
Connecting Arm Cover B (R)
2
24
Ø31 × Ø25.5 × Ø19 × 16+3T_Bushing
4
61
Middle Stabilizer Cover
2
25
Steel Cable
1
62
Rear Stabilizer Cover (L)
1
26
Drive Belt
1
63
Rear Stabilizer Cover (R)
1
27
Ø330_Drive Pulley
1
64
Ø40 × Ø80_Oval End Cap
2
28
Flywheel
1
65
Ø60_Transportation Wheel
2
29
Magnet
1
66
Ø31.8 × 3T × 420m/m_Handgrip
Foam
2
30
25 × 7 × 7m/m_Woodruff Key
2
67
Ø32 × 28T_Rubber Foot
2
31
Console Assembly
1
69
Bushing
1
32
1000m/m_Computer Cable
1
70
5/16" × 15m/m_Hex Head Bolt
14
33
600m/m_DC Power Cable
1
71
5/16" × 32m/m_Hex Head Bolt
2
34
Gear Motor
1
72
1/4" × 3/4"_Hex Head Bolt
4
35
300m/m_Sensor W/Cable
1
73
3/8" × 2-1/4"_Socket Head Cap Bolt
2
37
800m/m_Handpulse W/Cable
Assembly
2
74
M8 × 25m/m_Socket Head Cap Bolt
2
