Battery Charger RE
User's Manual
4. Installation
The charger is marked with a technical label, containing the following data:
• Model;
• Serial number (S/N);
• Weight (kg);
• Input voltages (V);
• Maximum input current (A);
• Maximum input power (KVA);
• Input frequency (Hz);
• Battery voltage (V);
• Maximum output current (A).
Conditions of use:
• Operating temperature: 5°C to 45°C
• Storage temperature: -20°C to 60°C
• Relative humidity: less than 75%
OWM-040906-RE Version: 02-AB Page 8 of 24
CAUTION !
The charger can be installed by qualified personnel only.
NOTE
This unit operates on 220-230-240 V AC, 50Hz.
Check that the unit's operating voltage is identical to your local power supply.
Check that the unit's maximum input power is available from your power supply.
CAUTION !
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
Do not use the unit in presence of flammable gas, because it can be generate sparks.
