[0203072TSS] TSS-D Battery Chargers r1
User's Manual
5. TROUBLE SHOOTING
SYMPTOM POSSIBLE CAUSES ACTION
Charger does
not react to
battery being
connected, and
display remains
OFF.
1 Battery not connected properly. Check battery connectors/harness.
2
Charger has been connected to
forklift motor connector.
Disconnect forkift motor and
connect battery.
3 Output fuse blown. Replace output fuse and adjust AC input settings.
4 Output cables reversed.
Check charger, connectors and battery polarities.
Output fuse is probably blown.
5 Bad control board connection. Check board connectors (green).
6 Bad control board. Replace control board.
When battery is
connected,
message
appear.
1 AC input is absent.
Check AC input voltage on each phase.
Check AC input connections.
Check AC disconnect switch and fuses.
2 Bad contactor. Replace contactor and freewheeling diode.
Output current
is too high
1 Wrong AC input settings. Adjust AC input settings to higher voltage.
2 One or more cells are shorted. Repair battery.
Output current
is too low
1 Wrong AC input settings. Adjust AC input settings to lower voltage.
2 One AC phase is absent. Check AC input voltage on each phase.
3 One or more diodes blown. Replace rectifier.
4 Bad contactor. Replace contactor.
Charger
smells hot
1
Bad location.
Install the charger in proper location.
2 Ventilation slots obstructed. Remove objects which may obstruct slots.
3 Wrong AC input settings. Adjust AC input settings to higher voltage.
4 Bad or loose power wirings. Check and thighten all power wirings.
5 Transformer burned. Replace transformer.
Charger
too noisy
1 Bad contactor. Replace contactor and freewheeling diode.
2 One or more diodes shorted. Replace rectifier.
Battery has low
S.G. and/or
doesn't
last full shift
1 Wrong AC input settings. Adjust AC input settings to lower voltage.
2 Battery capacity too low. Replace battery.
Battery
temperature
too high.
1 Wrong AC input settings. Adjust AC input settings to higher voltage.
2 Battery power demand too high. Consider purchasing bigger Ah battery.
3 Insufficient cool down time. Increase cool down time before/after charging.
4 Automatic stop doesn't work. Check and replace board and/or contactor.
__________________________________________________________________________________________________________________________________________________
Page 19/19
