7
11. REPLACING THE FUSE
A fuse holder is located
on the back of the unit
next to the power cord.
To replace or check the
fuse, remove the fuse
holder by pressing on
the clip and pulling straight out.
If the fuse is blown, replace with the backup fuse. Insert the new fuse into the fuse
holder. Press the assembly straight in until it latches.
If the fuse holder cap is not installed correctly, the unit will not operate.
110 volt models: fusing current no more than1.0 Amp.
230 volt models: fusing current no more than 1.0 Amp.
12. TROUBLE SHOOTING GUIDE
Indicators of Operation (Operation of the ozone and power indicator lamp).
Ozone switch is suggested to be operated when a
room is unoccupied. Open the door and window
when you come back to the room if the Ozone
mode has been operating for several hours.
Turn the unit on and check that the small
red/orange lamp is illuminated. The lamp is located
on front panel; one is silkscreen ‘power’ anther is
silkscreen ‘ozone’.
Troubleshooting - What to look for first.
⑴. I have plugged in the unit, turned the power switch to "On" and nothing
happens. What's wrong?
Make sure the electrical outlet is capable of providing power to the unit.
Check the back cover located at the back of the unit to ensure that the
safety switch activator clip is suppressed to get the power on.
Check to see if the proper fuse is installed and that it is serviceable.
Ensure that the fuse cap is completely seated and secured in its
receptacle.
Be sure the cord is fully plugged into unit.
⑵. The fan is operating but the unit won't produce any ozone. What's wrong?
Check the air purifier plate(s) for serviceability. If they are cracked or
