Installation and Operation Requirements - Solution 2.3
ENGLISH
2.3.5 Combustion Chamber Dimensions
9"
227mm
17 1/2"
444mm
Figure 13: Door Opening
21"
533mm
11 7/8"
301mm
3/8"
10mm
3/16"
5mm
16 1/2"
419mm
Figure 14: Front View - Combustion Chamber Figure 15: Side View - Combustion Chamber
