Page 31
Installation and Operation Requirements - Solution 2.3
ENGLISH
6.4 Optional Airmate Installation
THE IMAGES SHOWN ARE FOR GUIDANCE ONLY AND MAY BE DIFFERENT FROM YOUR PRODUCT,
BUT THE ASSEMBLY REMAINS THE SAME.
1. Remove the deflector (A) and keep the screws (B).
A
B
2. Install the airmate (C) with the screws kept from the previous step (B).
B
