Page 28
Installation and Operation Requirements - Solution 2.3
ENGLISH
6.2 Pedestal Installation
THE IMAGES SHOWN ARE FOR GUIDANCE ONLY AND MAY BE DIFFERENT FROM YOUR PRODUCT,
BUT THE ASSEMBLY REMAINS THE SAME.
1. Remove the door, the firebricks and the ash plug
23
from the stove, if desired.
2. Put the stove on its back. Remove and dispose of the two freight supports (D). Keep the nuts
(C) and washers (B) for step 3.
B
C
23 If present on your product.
