Installation and Operation Requirements - Solution 2.3
ENGLISH
3. Install the pedestal (E) on the stove and screw it in place using washers (B) and nuts (C).
B
C
E
4. Put the stove on its pedestal and install the fresh air panel (F) with the screws (G), the air control
cover (H) (this step might not be required on your stove) with the screws (J) and install the ash
drawer (K). Put back the bricks, the spacers, the ash plug
24
and the door on the stove. (See
step 1)
G
F
H
J
K
The baffle
22
and the bricks must be put back in the right place after the final positioning of
the stove.
24 If present on your product.
