Page 37
Installation and Operation Requirements - Solution 2.3
ENGLISH
6.9 Mobile Home Installation
THE IMAGES SHOWN ARE FOR GUIDANCE ONLY AND MAY BE DIFFERENT FROM YOUR PRODUCT,
BUT THE ASSEMBLY REMAINS THE SAME.
1. For a stove on legs, install a plate (L) on each leg and screw it in place with the proper hardware (M).
L
4x
M
4x
2. For a stove on a pedestal, remove the plugs (N) and screw the base on the floor with the proper
hardware (O).
N
O
