Page 43
Installation and Operation Requirements - Solution 2.3
ENGLISH
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts
for your unit, please provide the model number and the serial number. We reserve the right to
change parts due to technology upgrades or availability. Contact an authorized dealer to obtain
any of these parts. Never use substitute materials. Use of non-approved parts can result in poor
performance and safety hazards.
# Item Description Qty
1 AC01315 RIGID FIRESCREEN 1
2 SE74166 HANDLE 30898 REPLACEMENT KIT 3
3 SE24358 SOLUTION 2.3 CAST IRON DOOR ASSEMBLY 1
4 SE70698 REPLACEMENT HANDLE WITH LATCH KIT 1
5 AC09185 DOOR LATCH KIT 1
6 30101 SPRING TENSION PIN 5/32"Ø X 1 1/2"L 1
7 AC06500 SILICONE AND 5/8" X 8' BLACK DOOR GASKET KIT 1
8 SE74822 GLASS WITH GASKET 17 11/16'' L X 11 5/8'' H 1
9 AC06400 3/4" X 6' FLAT BLACK SELF-ADHESIVE GLASS GASKET 2
10 SE74173 GLASS FRAME KIT 1
11 SE53585 GLASS RETAINER KIT WITH SCREWS (12 PER KIT) 1
12 SE74103 SOLUTION 2.3 ASH LIP 1
13 30507 BLACK TORX SCREW WITH FLAT HEAD TYPE F 1/4-20 X 3/4" 3
14 SE74168 AIR CONTROL DAMPER ASSEMBLY 1
15 AC01295 BLACK CAST IRON ROUND LEGS WITH ASH DRAWER 1
15 AC01296 BRUSHED NICKEL CAST IRON ROUND LEGS WITH ASH DRAWER 1
16 SE65867 ASH PAN ASSEMBLY 3
17 30141 LEG KIT HARDWARE BAG 3
18 30050 LEVELING BOLT 3/8-16 X 1 1/2" 12
19 24284-01 BRUSH NICKEL PLATED CAST IRON LEG (BLACK PAINT IN THE BACK) 4
19 PL24284 LEG HIGH NATURAL RAW CASTING - BLACK 4
20 AC01208 BRUSHED NICKEL CAST IRON TRADITIONAL LEGS WITH ASH DRAWER 1
20 AC01206 BLACK CAST IRON TRADITIONAL LEGS WITH ASH DRAWER 1
21 PL24012 BLACK PAINTED CAST IRON LEG WITH LEVELING BOLT 4
21 PL24012PN NICKEL PLATED CAST IRON LEG WITH LEVELING BOLT 4
22 AC01294 BRUSHED NICKEL CAST IRON FLARED LEGS WITH ASH DRAWER 1
22 AC01293 BLACK CAST IRON FLARED LEGS WITH ASH DRAWER 1
23 PL24283 LEG CURVED NATURAL RAW CASTING - BLACK 4
23 24283-01 BRUSH NICKEL PLATED CAST IRON LEG (BLACK PAINT IN THE BACK) 4
24 AC01124 PEDESTAL WITH ASH DRAWER 1
25 PL74160 AIR CONTROL COVER 1
26 SE65956 ASH PAN 1
27 31125 PEDESTAL KIT HARDWARE BAG 1
28 AC01336 5"Ø FRESH AIR INTAKE KIT FOR WOOD STOVE ON PEDESTAL 1
29 49028 5" WHITE AIR INTAKE TERMINATION 1
