Solution 2.3 Installation and Operation Manual 47
Appendix 2: Installing the Door Overlay
In order to complete the assembly of your Solution 2.3 wood stove, you need to install the door
overlay. See figure below for installation instructions:
Position the overlay (A) on the door
frame and secure it from the inside of
the door using the 4 included screws
(B).
To facilitate the installation, do not
tighten the screws until they are all
installed.
Note: It is not necessary to remove the
glass or any other component to install
the overlay
