50 Solution 2.3 Installation and Operation Manual

Appendix 5: Installing the Fresh Air Kit (AC01316 / AC01336)

This mobile home approved stove requires installation of a fresh air kit (A) and an insulated fresh

air intake pipe (B), sold separately.

Installation on the back (AC01336):
