ENFORCER E-921APQ User Manual

ENFORCER Auto Dialer
14 SECO-LARM U.S.A., Inc.
Program Planner:
Program: Numbers
Date:
NUMBER
PRIORITY
TELEPHONE NUMBER
(include area code and dialer prefix as needed, add
PBX pause and extension if applicable, see p. 6-7)
NAME OF PARTY TO BE REACHED
1
2
3
4
5
For Future Use
Installation
: Triggers
Date:
TRIGGER
GENERAL DESCRIPTION
SENSOR LOCATIONS
1
2
Use these charts during setup to record phone numbers and sensor locations for future reference.
It is recommended that you use a pencil during setup and redo it in ink afterwards. The user
should keep in a safe, easily accessible location and a copy should be retained by the installer.
ENFORCER Auto Dialer
SECO-LARM U.S.A., Inc. 3
Back Connection Area (Cover Removed)
Wiring Diagram:
Trigger 1 Trigger 2
Siren
Output+
125mA Max.
DC+
9~12VDC
ENFORCER
®
Reset
GRD
COM.
or
Telephone Wall Jack
External Alarm/Siren
Power Adapter
(3.5mm Phone P
lug,
Not Included)
+
-
External Power
Supply
+
-
SM
-
206Q*
E
-
964
-
D390Q*
* E
-
96
4
-
D390Q Photobeam Detectors, SM
-
200
Q
Magnetic
Sensors, and SM-206Q Concealed Magnetic Sensors shown as
examples only: For other sensors and products available from
SECO
-
LARM, please visit our website at www.seco
-
larm.com
.
SM
-
200Q*
Operating voltage
9~12 VDC
Current draw
Max. (at 12VDC)
Standby
5mA
Dialing
10
mA
Alarm On
1
8
0mA
Programmable emergency phone numbers
5
Maximum digits per telephone number
32
Backup battery type/life (not
included)
9VDC/≈20h
Alarm sound level at 12" (30cm)
≥
105dB
Trigger inputs
2 x N.C. Trigger
Trigger input timer
≥500ms
Auxiliary output current (max)
125mA
Operating temperature
32
°
~104°F (0
°
~40°C)
Storage temperature
-
4
°
~140°F (
-
20
°
~60°C)
Weight
6.2
-
oz (175g)
Dimensions
3
3
/
8
"
x4
5
/
16
"
x1
7
/
8
"
(
86
x11
0
x4
7
mm)
Specifications:
1x
Auto dialer unit
1x
Telephone cable
1x
Remote control instruction card
1x
Dual outlet telephone jack adapter
2x
Plastic wall anchors
2x
Wall mount screws
1x
Wall mounting template
1x
User manual
Parts List:
