Engcon DC2 Installation Instructions

21
engcon DC2
5�6 Decals for multiple user banks
Ifmorethanoneuserbankisactivated,theinstallermusta󰀩xonedecalperuserbank.
Thecabmodulemustthenalsobettedsothatthedrivercanseethedisplayandthere-
by see which user bank is active.
The installer is then responsible for ensuring that there is one decal per user bank and
that the base machine's instruction manual is updated with this information.
Pos Designation
1 The current user is shown in the display
2 Each user must have a corresponding decal
1
2
USER 1
USER 1 USER 2 SHEAR

Engcon DC2 Specifications

General

Brand	Engcon
Model	DC2
Category	Controller
Language	English
