Engcon MIG2 CAN - Fit Attachment Bolt and Lock Nut

4 Installation
4.3. Installing the MIG2 CAN
4.3.1. Fitting the attachment bolt and lock nut
Fit the lock nut from the original joystick and attachment bolts in the control valve where
the original joystick was previously installed.
REMARKS
It may be necessary to cut the attachment bolt to a suitable
length before installing as illustrated below.
1
2
Position
Description
1
Attachment bolt
2
Lock nuts
12
