2 SAFETY INSTRUCTIONS
Read carefully these instructions before connecting the unit.
The operating voltage is indicated on the adapter.
To prevent re, short circuit, shock hazard:
Do not expose the unit to rain or moisture.
Install the unit in a dry location without inltration or condensation of water.
Do not expose it to dripping or splashing.
Do not place objects lled with liquids, such as vases, on the apparatus.
If any liquid should accidentally fall into the cabinet, disconnect the power plug.
Refer to qualied technician before it’s further operation.
To avoid any risk of overheating:
Install the unit in a well aery location and keep a minimum distance of 15 cm around the apparatus for
sufcient ventilation.
Do not place any items such as newspapers, table-cloths, curtains ... on the unit that might cover the
ventilation holes.
The unit must not be exposed to any source of heat (sun, heater,...).
Do not place any naked ame sources, such as lighted candles, on the apparatus.
Do not install the product in a dusty place.
Pull out power plug to make the different connections of cables.
To avoid electrical shock, do not open the housing of adapter.
Cleaning: Only use a dry soft cloth to clean the cabinet. Do not use solvent.
Servicing: For repairing and servicing refer to qualied personnel.
3 MOUNTING
(1) Earthing.
(2) Place the adapter in its holder.
(3) Connect the power supply to
the amplier.
(4) Plug the mains cable to
the adapter.
(5) Click the adapter holder
to the amplier.
212.5 mm
185 mm
