50
51
5 OPERATION
All parameters are set with the rotary push button.
Each function and parameters are shown on 2 digits display and different LEDs.
PROGRAMMING:
Enter Programming Mode
- Make all the necessary connections and connect amplier to mains.
The software version is displayed,
followed by a dot.
- Push on the rotary button for more than 3 seconds to enter into programming mode.
3 seconds
Repeat this section to set all parametres
- Turn the button to select the desired mode.
Mode is indicated with = green LED
a GREEN colored LED. = red LED
- Push the rotary button to enter the selected mode.
The LED is now RED colored.
- Inside the mode, turn the button to select the parameter (input, cluster, channels, level...)
Display
Input and Cluster LEDs
