- Push the button to conrm the parameter setting.
LED returns to a GREEN color.
Exit Programming Mode
- Turn the button select Exit mode.
The LED is GREEN.
- Push the button to conrm.
A dot is displayed.
Note: The amplier will go in “stand-by” and will display a dot after 1 minute if the rotary / push button
is not activated.
6 CLUSTER PROGRAMMING
SETTING CLUSTERS / UHF INPUT:
- The amplier has 3 UHF inputs which are splitted over 10 clusters.
There are three possible congurations:
Input UHF1 UHF2 UHF3
Number 2 8 0 UHF1 clusters are indicated by the YELLOW LEDs n° 1 and 2.
of 2 7 1 UHF2 clusters are indicated by the RED LEDs n° 3, 4, 5, 6, 7, 8, 9 and 10.
cluster(s) 2 5 3 UHF3 clusters are indicated by the GREEN LEDs n° 8, 9 and 10.
Exit
