Electrical System
A NEGATIVE EARTH (NEGATIVE GROUND) SYSTEM IS USED.
ECU - Power Distribution Box
Generator
This is mounted on a bracket at the front of the engine and is driven from the crankshaft by a
serpentine belt.
The charging rate is adjusted automatically by the built-in regulator to provide sufficient electric
current to keep the battery fully charged under normal operating conditions.
The generator requires no lubrication or maintenance.
WARNING: IT IS ESSENTIAL THAT THE WIRING CONNECTIONS TO THE GENERATOR ARE
NOT REMOVED WHILE THE ENGINE IS RUNNING, AS THIS WILL RESULT IN DAMAGE TO
THE REGULATOR OR PERSONAL INJURY.
