IQ8 / IQ8+ / IQ8M / IQ8A / IQ8H Micro Installation and Operation
31 © 2022 Enphase Energy Inc. All rights reserved. Mar 2022
Enphase IQ Cable Accessories
The Enphase IQ Cable is available with several accessory options for ease of installation, including:
• Field wireable connectors (male): (Q-CONN-10M) Make connections from any Field Wireable female connector
• Field wireable connectors (female): (Q-CONN-10F) Make connections from any IQ Cable open connector or Field
Wireable male connector
• Cable clips: (Q-CLIP-100) Used to fasten cabling to the racking or to secure looped cabling
• Disconnect tool: (Q-DISC-10) Disconnect tool for IQ Cable connectors, DC connectors, and AC module mount
• IQ Cable sealing caps (female): (Q-SEAL-10) One needed to cover each unused connector on the cabling
• Terminator: (Q-TERM-10) Terminator cap for cut cable ends
