Page 26 of 72 EN109-1498751-47 IFU
Ramp down time, expressed in seconds, defines the time in a surge program during which the
current is decreased from the adjusted level to 0. See Figure 30 for details. The ramp down time can
be adjusted in increments of 0.1 second.
Interval time, expressed in s, defines the time in a surge program during which the current is kept at
0. See Figure 30 for details. The interval time can be adjusted in increments of 1 second.
Delay time, expressed in seconds, defines the time delay between the start of the surge program on
channel 1 and channel 2. See Figure 30 for details. The delay time can be adjusted in increments of 0.1
second.
Beep, if enabled, generates a short beep at the start of each surge.
Navigation
Electrotherapy
Home
The Home menu gives access to all functions of the unit. Select
the desired function or therapy by touching the button.
The next screen appears.
Electrotherapy “Clinical Protocols”
The electrotherapy menu gives access to functions
• Clinical Protocols
• Favorites
• Manual Operation
• Programming
Select Clinical Protocols by touching the button.
The next screen appears.
