Enraf Nonius 4 Series User Manual

Page 57 of 72 EN109-1498751-47 IFU
Pulse Frequency : 1 – 200 Hz, in steps of 1 Hz
Frequency Modulation : 0 – 180 Hz, in steps of 1 Hz
Modulation Program : 1/1, 6/6, 12/12, 1/30/1/30 s
Surge Program : Yes
Amplitude : 0 - 140 mA
Asymmetrical Alternating
Phase Duration : 10 – 400 µs in steps of 5 µs
Pulse Frequency : 1 – 200 Hz, in steps of 1 Hz
Frequency Modulation : 0 – 180 Hz, in steps of 1 Hz
Modulation Program : 1/1, 6/6, 12/12, 1/30/1/30 s
Surge Program : Yes
Amplitude : 0 – 140 mA
Burst Asymmetrical
Phase Duration : 10 – 400 µs in steps of 5 µs
Pulse Frequency : 1 – 200 Hz, in steps of 1 Hz
Burst Frequency : 1 – 9 Hz, in steps of 1 Hz
Amplitude : 0 – 140 mA
Burst Asymmetrical Alternating
Phase Duration : 10 – 400 µs in steps of 5 µs
Pulse Frequency : 1 – 200 Hz, in steps of 1 Hz
Burst Frequency : 1 – 9 Hz, in steps of 1 Hz
Amplitude : 0 – 140 mA
Symmetrical
Phase Duration : 10 – 400 µs in steps of 5 µs
Pulse Frequency : 1 – 200 Hz, in steps of 1 Hz
Frequency Modulation (spectrum) : 0 – 180 Hz in steps of 1 Hz
Modulation Program : 1/1, 6/6, 12/12, 1/30/1/30 s
Surge Program : Yes
Amplitude : 0 – 140 mA
Burst Symmetrical
Phase Duration : 10 – 400 µs in steps of 5 µs
Pulse Frequency : 1 – 200 Hz, in steps of 1 Hz
Burst Frequency : 1 – 9 Hz, in steps of 1 Hz
Amplitude : 0 – 140 mA
Premodulated
Carrier Frequency : 2, 2.5, 3, 3.5, 4, 5, 6, 7, 8, 9, 10 kHz
Beat Frequency : 0 – 200 Hz in steps of 1 Hz
Frequency Modulation (spectrum) : 0 – 180 Hz in steps of 1 Hz
Modulation Program : 1/1, 6/6, 12/12, 1/30/1/30 s
Surge Program : Yes
Amplitude : 0 – 100 mA
Russian Stimulation
Carrier Frequency : 2, 2.5, 3, 3.5, 4, 5, 6, 7, 8, 9, 10 kHz
Burst Frequency : 0 – 100 Hz in steps of 1 Hz
