Page 58 of 72 EN109-1498751-47 IFU
Burst / Pause : 1:1, 1:2, 1:3, 1:4, 1:5
Surge Program : Yes
Amplitude : 0 – 100 mA
High Voltage (Twin Pulse)
Frequency : 1 – 200 Hz in steps of 1 Hz
Frequency Modulation (spectrum) : 0 – 180 Hz in steps of 1 Hz, sum of Pulse frequency and
Frequency Modulation cannot exceed 200 Hz
Modulation Program : 1/1, 6/6, 12/12, 1/30/1/30 s
Surge Program : Yes
Polarity : Positive or Negative
Amplitude : 0 – 500 Volt in steps of 1V
High Voltage Alternating (Twin Pulse)
Frequency : 1 – 200 Hz in steps of 1 Hz
Frequency Modulation (spectrum) : 0 – 180 Hz in steps of 1 Hz, sum of Pulse frequency and
Frequency Modulation cannot exceed 200 Hz
Modulation Program : 1/1, 6/6, 12/12, 1/30/1/30 s
Alternating Period : 10 – 100 seconds in steps of 10 s
Ramp up, ramp down : 0.5 seconds
Amplitude : 0 – 500 Volt in steps of 1 Volt
Micro Current
Frequency : 0 – 1000 Hz
Polarity : Positive or Negative
Surge Program : Yes
Amplitude : 10 µA – 1 mA in steps of 10 µA
Micro Current Alternating
Frequency : 0 – 1000 Hz, 0 – 100 Hz in steps of 0.1 Hz, 10 – 100 Hz in steps
of 1 Hz, 100 – 1000 Hz in steps of 10 Hz
Alternating Period : 0,2 – 20 seconds, 0,2 – 1 s in steps of 0.1s, 1 – 20 s in steps of 1
s
Ramp up, ramp down : 0 seconds
Amplitude : 10 µA – 1 mA in steps of 10 µA
Diadynamic current
Settings : MF, DF, CP, LP and CPid
Surge Program : on MF and DF
Polarity : Positive or Negative
Amplitude : 0 – 70 mA
MF interrupted galvanic current
Frequency : 8000 Hz
Duty cycle : 95%
Polarity : Positive or Negative
Amplitude : 0 – 40 mA
Direct Galvanic current
Polarity : Positive or Negative
Amplitude : 0 – 40 mA
