OEX-6sr Information
OEX-6sr Information
The OEX-6sr is a multi-function digital device that adds six individual outputs or three additional pairs
of stereo outputs to an ASR-10 Keyboard or EPS-16 PLUS keyboard. The OEX-6sr comes standard on
the ASR- 10 Rack.
The OEX-6sr enhances the capabilities and flexibility of the ASR-
lO/EPS-
16 PLUS.
The power of the OEX-6sr Output Expander lies in its unique configuration:
six individual outputs or
three stereo pairs (AUX 1, AUX 2, AUX 3). The addition of these outputs allows you to route separate
signals for independent processing, or isolate parts for click or monitoring references. Even individual
WaveSamples within an instrument (for instance, the snare and kick drum from a drum kit) can be sent
to different outputs for discrete external effects processing (such as with the ENSONIQ DP/4 Parallel
Effects Processor). The design of this product resulted from customer requests for a multi-purpose
output device that could be configured with stereo outputs and/or individual outputs.
IMPORTANT! Because the OEX-6sr is a digital device, no audio signal passes through the connector
cable from the ASR-lo/BPS-16 PLUS to the OEX-6sr. Do not connect this cable to any other device
that uses a similar connector (such as a Macintosh), as this will damage both units and void their
warranties.
,
Important points about the OEX-6sr
l Never connect the OEX-6sr while the power to the
ASR-lO/EPS-16
PLUS is on. This will damage
both units and void their warranties.
l The signals sent to AUX 1, AUX 2, and AUX 3 on the OEX-6sr are dry; these outputs do not pass
signals with effects. The wet signal is only present at the Main Audio Outputs.
l The AUX 1, AUX 2, and AUX 3 outputs on the OEX-6sr are always active when the OEX-6sr is
connected.
l The Outputs on the OEX-6sr are not affected by the
ASR-lO/EPS-16
PLUS master Volume Slider.
l Assigning of sounds to the OEX-6sr can be handled two ways; at the WaveSample level or at the
track level.
ASR Service Manual
77
