GLOSSARY
SIMMs that contain more than one size of RAM chip. These SIMMs
may also contain GAL (Gate Array Logic) or PAL (Programmable
Array Logic) chips. Do not use these SIMMs in an ASR product.
Nuts with star washers attached
A screw with a patch of nylon on the threads for greater holding
power.
Threaded mounting standoff for screws.
An angled tool, useful for disconnecting cables without damaging
them.
Small Computer System Interface.
Screws with star washers attached.
Single In-line Memory Module
Termination filters out noise introduced by hard drives or computer
power supplies so the noise doesn’t confuse the SCSI software.
MODULE PART NUMBERS
Kevboard
409OO17OO1/5
409OO17101
409OO17201
409OO17301
409OO17701
409OO17401
409OO17801
4090016901
4090018701
Rack
409OO17002/6
409OO17102
409OO17201
409OO17302
409Oo17702
409OO18801
not used
409OO16901
40900 18702
ASR-88
409OO17010
4090017101
409OO17201
409OO17301
40900 17703
409OO17401
4090016901
4090016901
409OO18701
