MN-28646 • Rev 4 • 03/18 • EC Series Fluid Combination Blanket/Fluid Warmer
7
Dimensions
27.1" (689mm)
25.4" (646mm)
12.5"
(318mm)
CAVITY
32.5"
(826mm)
CAVITY
23.3" (592mm)
CAVITY
28.8" (732mm)
73.4" (1864 mm)
26.7" (678mm)
CAVITY
31.1" (790mm)
ON
OFF
LOCK
TIME START
STOP
TIMER
ON
OFF
OVER
TEMP
IRRINJ
LOCKOVERTEMP
ERROR
27.6" (700mm)
INSERT
4.6"
(117mm)
4.0"
(102mm)
CORD LENGTH
8' (2,438mm) (est.)
27.1" (688mm)29.0" (736mm)
30.2" (767mm)
6.7"
(171mm)
70.9" (1801mm)
24.6" (625mm)
INSERT
55.1" (1400mm)
EC1730BL
