Pg. 5
HA8-LP Manual V. 4.0
Completed/Typical Automatic Door Installation
BACKING MATERIAL
(REINFORCEMENT)
LOW PROFILE
OPERATOR
ARM
CONTROL BOARD
HEADER BODY
HEADER COVER
HINGE STILE
DOOR MOUNTED
SENSORS HERE
(OPTIONAL)
ANSI STICKERS
KNOWING ACT DEVICE
INSIDE AND OUTSIDE
(FOR LOW ENERGY ONLY)
STRIKE STILE
SWING DOOR
DOOR FRAME
